Double head cutting machine aluminium cum

Double head cutting machine aluminium cum

Name: Double head cutting machine aluminium cum
Brand: SHRI BABA JI INDUSTRIES
Price: 450000 INR
Availability: InStock

450000 INR/Piece

Get a Price/Quote

Product Details:

Drive Motor High efficiency induction motor
Product Type Aluminium Cum Double Head Cutter
General Use Aluminium profile cutting for windows, doors, facade industry
Material Aluminium profiles, light metals
Type Double Head Cutting Machine
Capacity 2-6 m/min
Weight (kg) Approx. 600 kg
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Double head cutting machine aluminium cum Price And Quantity

Price 450000 INR/Piece
Minimum Order Quantity 01 Piece

Double head cutting machine aluminium cum Product Specifications

Automatic Fully automatic operation
Material Aluminium profiles, light metals
Cutting Material Aluminium, PVC, light alloy extrusions
Cooling System Spray lubrication system
Dimension (L*W*H) approx. 5500mm x 1200mm x 1600mm
Cutting Area Up to 420mm x 120mm
Product Type Aluminium Cum Double Head Cutter
Feature High precision, automatic feed, safety covers, digital display
Motor Powerful industrial 3.0 kW motor
Voltage 380V/50Hz, 3 Phase
Weight (kg) Approx. 600 kg
Cutting Function Accurate double miter cut, angle adjustable
Capacity 2-6 m/min
General Use Aluminium profile cutting for windows, doors, facade industry
Computerized Yes
Drive Motor High efficiency induction motor
Mechanical Precision 0.1 mm
Type Double Head Cutting Machine
Control System PLC based
Color Industrial grey with blue highlights
Cutting Method Cold cutting, straight/miter cuts
Software Detail PLC Controlled, touch screen interface
Drive Type Servo Motor
Cutting Speed Variable; up to 3000rpm
Cutting Thickness Max 3-5 mm (material dependent)

Double head cutting machine aluminium cum Trade Information

Payment Terms Cash Advance (CA), Cash in Advance (CID)
Main Export Market(s) Australia, Central America, South America, Western Europe, Middle East, Eastern Europe, Asia, North America, Africa
Main Domestic Market All India

Product Description

Double head cutting machines for aluminum are designed to efficiently cut aluminum profiles for various applications, including window and door manufacturing, curtain walls, and other industrial uses. These machines feature two cutting heads that can operate simultaneously or independently, enhancing productivity and precision.

Key Features:

- Dual-Head Design: Allows for simultaneous cutting of two profiles, increasing efficiency and reducing processing time.

- High-Precision Cutting: Equipped with advanced CNC technology, ensuring accurate cuts and minimal material waste.

- Adjustable Cutting Speed: Enables operators to customize cutting speeds based on material type and thickness.

- Automatic Safety Features: Includes self-closing protective hoods and emergency stop functions to ensure operator safety.

- Pneumatic Clamping System: Provides secure and precise clamping of profiles during cutting operations

Popular Brands and Prices:

When selecting a double head cutting machine for aluminum, consider factors such as cutting capacity, precision, and automation level to ensure the best fit for your specific needs.

Advanced Precision and Flexibility

Engineered for professional aluminium profile cutting, this double head machine ensures repeatable precision (0.1mm) thanks to its servo-driven system and PLC-controlled operations. Adjustable heads enable both straight and miter cuts for various fabrication needs, supporting industries such as windows and facades.

Superior Safety and Efficiency

With integrated safety features including interlocked covers, emergency stop, and dual-hand controls, operators work confidently. The integrated dust extraction port and automatic lubrication enhance usability and machine longevity, minimizing downtime and maintenance efforts.

User-Friendly Interface and Versatility

Its LCD touch screen interface and computerized PLC system allow seamless operation in manual, semi-automatic, or fully automatic modes. Pneumatic clamping guarantees stable positioning for every cut, supporting high throughput and a wide variety of aluminum, PVC, and light metal profiles.

FAQ's of Double head cutting machine aluminium cum:

Q: How do you adjust the cutting angle on this double head cutting machine?

A: The cutting angle can be adjusted between 45 and 90 on both heads. Adjustment can be carried out either manually or using the motorized head movement feature, depending on the operator's preference and application requirements.

Q: What safety mechanisms are incorporated into the machine during operation?

A: For operator safety, the machine includes interlocked safety covers, emergency stop buttons, and a two-hand control system to prevent accidental activation, ensuring safe operation during all cycles.

Q: When is the automatic micro-lubrication system activated and why is it important?

A: The automatic micro-lubrication system activates during cutting processes to keep the blade cool and lubricated. This enhances blade durability, ensures smoother cuts, and prevents heat buildup that could damage materials or the blade itself.

Q: Where is the integrated dust extraction port located, and what is its purpose?

A: The integrated dust extraction port, featuring a 100mm outlet, is positioned near the cutting area to efficiently remove debris and dust generated during cutting, thus maintaining a cleaner workspace and protecting internal machine components.

Q: What is the process for changing operation modes on the machine?

A: Operation modes (manual, semi-automatic, or fully automatic) can be changed directly via the LCD touch screen interface, giving operators the flexibility to adapt workflow to production needs and material types using PLC control.

Q: How does the pneumatic vertical clamping system benefit the cutting process?

A: The pneumatic vertical clamping system securely holds profiles in place, minimizing material movement during cutting. This ensures consistent accuracy (0.1mm repeatability) and high-quality, burr-free cuts across a range of profile sizes.

Q: What are the main advantages of using this computerized double head cutting machine?

A: Key benefits include high cutting precision, adjustable angles, automatic feed, variable speed control, robust safety features, and minimal noise (<75 dB). It streamlines window, door, and facade manufacturing by enabling fast, repeatable, and automated cutting for various light metal extrusions.
